QUANTECH
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 5 – TECHNICAL DATA
55
SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
57.7 284 57.7 284 57.7 284 2 7.6 44 57.7 284 57.7 284 57.7 284 2 7.6 44
57.7 330 57.7 330 57.7 330 2 7.4 37 57.7 330 57.7 330 57.7 330 2 7.4 37
30.9 192 30.9 192 30.9 192 2 4.5 23.1 30.9 192 30.9 192 30.9 192 2 4.5 23.1
26.9 180 26.9 180 26.9 180 2 4 19 26.9 180 26.9 180 26.9 180 2 4 19
21.5 132 21.5 132 21.5 132 2 2.9 15.3 21.5 132 21.5 132 21.5 132 2 2.9 15.3
57.7 284 57.7 284 57.7 284 3 7.6 44 57.7 284 57.7 284 57.7 284 3 7.6 44
57.7 330 57.7 330 57.7 330 3 7.4 37 57.7 330 57.7 330 57.7 330 3 7.4 37
30.9 192 30.9 192 30.9 192 3 4.5 23.1 30.9 192 30.9 192 30.9 192 3 4.5 23.1
26.9 180 26.9 180 26.9 180 3 4 19 26.9 180 26.9 180 26.9 180 3 4 19
21.5 132 21.5 132 21.5 132 3 2.9 15.3 21.5 132 21.5 132 21.5 132 3 2.9 15.3
106.2 523 106.2 523 3 7.6 44 106.2 523 106.2 523 3 7.6 44
106.2 578 106.2 578 3 7.4 37 106.2 578 106.2 578 3 7.4 37
64.3 355 64.3 355 3 4.5 23.1 64.3 355 64.3 355 3 4.5 23.1
53.1 290 53.1 290 3 4 19 53.1 290 53.1 290 3 4 19
42.5 255 42.5 255 3 2.9 15.3 42.5 255 42.5 255 3 2.9 15.3
106.2 523 106.2 523 2 7.6 44 106.2 523 106.2 523 2 7.6 44
106.2 578 106.2 578 2 7.4 37 106.2 578 106.2 578 2 7.4 37
64.3 355 64.3 355 2 4.5 23.1 64.3 355 64.3 355 2 4.5 23.1
53.1 290 53.1 290 2 4 19 53.1 290 53.1 290 2 4 19
42.5 255 42.5 255 2 2.9 15.3 42.5 255 42.5 255 2 2.9 15.3
106.2 523 106.2 523 3 7.6 44 106.2 523 106.2 523 3 7.6 44
106.2 578 106.2 578 3 7.4 37 106.2 578 106.2 578 3 7.4 37
64.3 355 64.3 355 3 4.5 23.1 64.3 355 64.3 355 3 4.5 23.1
53.1 290 53.1 290 3 4 19 53.1 290 53.1 290 3 4 19
42.5 255 42.5 255 3 2.9 15.3 42.5 255 42.5 255 3 2.9 15.3
106.2 523 106.2 523 4 7.6 44 106.2 523 106.2 523 4 7.6 44
106.2 578 106.2 578 4 7.4 37 106.2 578 106.2 578 4 7.4 37
64.3 355 64.3 355 4 4.5 23.1 64.3 355 64.3 355 4 4.5 23.1
53.1 290 53.1 290 4 4 19 53.1 290 53.1 290 4 4 19
42.5 255 42.5 255 4 2.9 15.3 42.5 255 42.5 255 4 2.9 15.3
57.7 284 57.7 284 57.7 284 4 7.6 44 57.7 284 57.7 284 57.7 284 4 7.6 44
57.7 330 57.7 330 57.7 330 4 7.4 37 57.7 330 57.7 330 57.7 330 4 7.4 37
30.9 192 30.9 192 30.9 192 4 4.5 23.1 30.9 192 30.9 192 30.9 192 4 4.5 23.1
26.9 180 26.9 180 26.9 180 4 4 19 26.9 180 26.9 180 26.9 180 4 4 19
21.5 132 21.5 132 21.5 132 4 2.9 15.3 21.5 132 21.5 132 21.5 132 4 2.9 15.3
TABLE 11 - ELECTRICAL DATA WITHOUT PUMPS (CONT’D)
