Quantech QTC3150THE User Manual

57
QUANTECH
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 5 – TECHNICAL DATA
55
TABLE 11 - ELECTRICAL DATA WITHOUT PUMPS (CONT’D)
SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
57.7 284 57.7 284 57.7 284 3 7.6 44 57.7 284 57.7 284 57.7 284 3 7.6 44
57.7 330 57.7 330 57.7 330 3 7.4 37 57.7 330 57.7 330 57.7 330 3 7.4 37
30.9 192 30.9 192 30.9 192 3 4.5 23.1 30.9 192 30.9 192 30.9 192 3 4.5 23.1
26.9 180 26.9 180 26.9 180 3 4 19 26.9 180 26.9 180 26.9 180 3 4 19
21.5 132 21.5 132 21.5 132 3 2.9 15.3 21.5 132 21.5 132 21.5 132 3 2.9 15.3
106.2 523 106.2 523 4 7.6 44 106.2 523 106.2 523 4 7.6 44
106.2 578 106.2 578 4 7.4 37 106.2 578 106.2 578 4 7.4 37
64.3 355 64.3 355 4 4.5 23.1 64.3 355 64.3 355 4 4.5 23.1
53.1 290 53.1 290 4 4 19 53.1 290 53.1 290 4 4 19
42.5 255 42.5 255 4 2.9 15.3 42.5 255 42.5 255 4 2.9 15.3
106.2 523 106.2 523 4 7.6 44 106.2 523 106.2 523 4 7.6 44
106.2 578 106.2 578 4 7.4 37 106.2 578 106.2 578 4 7.4 37
64.3 355 64.3 355 4 4.5 23.1 64.3 355 64.3 355 4 4.5 23.1
53.1 290 53.1 290 4 4 19 53.1 290 53.1 290 4 4 19
42.5 255 42.5 255 4 2.9 15.3 42.5 255 42.5 255 4 2.9 15.3
106.2 523 106.2 523 106.2 523 5 7.6 44 106.2 523 106.2 523 106.2 523 5 7.6 44
106.2 578 106.2 578 106.2 578 5 7.4 37 106.2 578 106.2 578 106.2 578 5 7.4 37
64.3 355 64.3 355 64.3 355 5 4.5 23.1 64.3 355 64.3 355 64.3 355 5 4.5 23.1
53.1 290 53.1 290 53.1 290 5 4 19 53.1 290 53.1 290 53.1 290 5 4 19
42.5 255 42.5 255 42.5 255 5 2.9 15.3 42.5 255 42.5 255 42.5 255 5 2.9 15.3
106.2 523 106.2 523 106.2 523 5 7.6 44 106.2 523 106.2 523 106.2 523 5 7.6 44
106.2 578 106.2 578 106.2 578 5 7.4 37 106.2 578 106.2 578 106.2 578 5 7.4 37
64.3 355 64.3 355 64.3 355 5 4.5 23.1 64.3 355 64.3 355 64.3 355 5 4.5 23.1
53.1 290 53.1 290 53.1 290 5 4 19 53.1 290 53.1 290 53.1 290 5 4 19
42.5 255 42.5 255 42.5 255 5 2.9 15.3 42.5 255 42.5 255 42.5 255 5 2.9 15.3
102.8 574 102.8 574 102.8 574 6 7.6 44 102.8 574 102.8 574 102.8 574 6 7.6 44
102.8 635 102.8 635 102.8 635 6 7.4 37 102.8 635 102.8 635 102.8 635 6 7.4 37
62.2 355 62.2 355 62.2 355 6 4.5 23.1 62.2 355 62.2 355 62.2 355 6 4.5 23.1
51.4 280 51.4 280 51.4 280 6 4 19 51.4 280 51.4 280 51.4 280 6 4 19
41.1 225 41.1 225 41.1 225 6 2.9 15.3 41.1 225 41.1 225 41.1 225 6 2.9 15.3
138.8 943 138.8 943 138.8 943 6 7.6 44 138.8 943 138.8 943 138.8 943 6 7.6 44
138.8 943 138.8 943 138.8 943 6 7.4 37 138.8 943 138.8 943 138.8 943 6 7.4 37
87.2 564 87.2 564 87.2 564 6 4.5 23.1 87.2 564 87.2 564 87.2 564 6 4.5 23.1
73 408 73 408 73 408 6 4 19 73 408 73 408 73 408 6 4 19
51.9 375 51.9 375 51.9 375 6 2.9 15.3 51.9 375 51.9 375 51.9 375 6 2.9 15.3
NOTES:
Reference PIN 59 for Pump Model.
Use this table along with Table 9 - Pump Electrical Data (60 Hz) on page 51 to determine electrical data of the unit plus the pump.
Does not include control transformer.
