14. View the video in real time to verify that the source is outputting video.
15. Set the capture trigger criteria and the pre-capture filtering criteria.
16. Initiate the capture.
17. View and analyze the captured data.
18. (Optional) If you have purchased the HDMI or MHL source compliance test option you can run this test series
as well. However you will have to refer to the User Guide for Compliance Tests for these procedures.
2.4 Front Panel
The 980 is equipped with a built-in color touch display that enables you to fully operate the 980 Protocol Analyzer.
There is a power button to turn the 980 Protocol Analyzer on (along with the rocker switch on back). The power
switch in the front is used when you are turning off the 980 Protocol Analyzer for a short period of time. For
extended periods of off time, it is best to power the 980 down by first using the power button on the front and then
the rocker switch on the back.
2.5 Connector Description
The 980 Protocol Analyzer (rear view shown in the photo below) provides the following connectors.
1. HDMI Rx connector (the top most HDMI connector shown in the figure below) enables you to monitor the
HDMI protocol from an HDMI source device.
2. HDMI Tx connector (the lower HDMI connector) can be used for pass through mode.
3. SPDIF input connector for injecting external SPDIF audio into an HDMI 1.4 stream with Audio Return Channel
(ARC) capabilities.
4. SPDIF output connector for extracting embedded SPDIF audio from an HDMI 1.4 stream with Audio Return
Channel (ARC) capabilities.
5. Ethernet input connector for injecting external Ethernet data into an HDMI 1.4 stream with HDMI Ethernet
Channel (HEC) capabilities.
6. Ethernet output connector for extracting embedded Ethernet data from an HDMI 1.4 stream with HDMI
Ethernet Channel (HEC) capabilities.
7. Ethernet jack on the lower left half of the back panel of the 980 Protocol Analyzer frame. This is used to
establish an IP session between the 980 GUI Manager running on the PC and the 980 Protocol Analyzer. The
IP address on this port is configurable.
8. Ethernet jack on lower right of back panel. This is used to establish an Ethernet connect between a Host PC
running the 980 GUI Manager or for connecting to the 882E/EA when running the HDMI Sink Compliance
Tests. Note that this IP address is fixed at: 192.168.10.1.
9. BNC connector for external trigger. This is used when you want an external input to trigger a capture.
