quantum
MASCHINEN - GERMANY
Technical Data
© 2007
GB
Page 1518 / 01 / 2008 Version 1.2.5 B 13 / B14 / B16 / B20 / B25 / B32 Drilling machine
2.10 Emissions
The emission of the drilling machine is below 76 dB(A). If the drilling machine is installed in an
area where various machines are in operation, the acoustic influence (immission) on the opera-
tor of the drilling machine may exceed 85 dB(A).
We recommend the use of soundproofing and ear protection.
Please note that the duration of the acoustic noise expose, the kind and nature of the working
area as well as other machines may influence the noise level in the workplace.
2.5 Dimensions
B 13 B 14 B 16 B 20 B 25 B 32
height [mm] 580 700 820 990 1570 1730
depth [mm] 420 420 510 700 690 790
width [mm] 220 230 270 300 390 400
total weight [kg] 21 24 38 56 63 138
column diameter [mm] 46 46 60 70 70 92
2.6 Working area
B 13 B 14 B 16 B 20 B 25 B 32
height [mm] 2050 2050 2050 2050 2050 2050
depth [mm] 2000 2000 2000 2000 2000 2000
width [mm] 1400 1400 1400 1400 1400 1400
2.7 Revolutions
B 13
B 14
B 16 B 20
B 25
B 20 Vario
B 25 Vario
B 32 B 32 Vario
spindle revolutions • 619
•837
•1314
•1807
•2435
• 459
• 579
• 787
• 1255
• 2100
•268
•323
•376
•453
•516
•533
•796
• 1029
• 1257
• 1274
• 1783
• 2209
• 16 - 686
• 19 - 827
• 22 - 963
• 27 - 1161
• 31 - 1323
• 32 - 1367
• 47 - 2041
• 61 - 2636
• 74 - 3221
• 75 - 3265
• 105 - 3500
• 131 - 3500
•167
•288
•339
•379
•489
•585
•1106
•1368
•1970
• 10 - 429
• 17 - 739
• 20 - 870
• 22 - 970
• 29 - 1253
• 35 - 1498
• 65 - 2835
• 81 - 3500
• 117 - 3500
2.8 Environmental conditions
B 13 B 14 B 16 B 20 B 25 B 32
temperature 5 - 35 °C
humidity 25 - 80 %
2.9 Operating material
toothed rack commercial slide bearing grease
drilling column acid-free lubricating oil
