Page 3318 / 01 / 2008 Version 1.2.5 B 13 / B14 / B16 / B20 / B25 / B32 Drilling machine
„Speed table“ on page 27
WARNING!
For drilling jobs, it is necessary to clamp the workpiece firmly to prevent the bit catching
on the piece. Example of suitable clamping devices include a machine vice or clamping
jaws.
Put a wooden or plastic board beneath the workpiece to avoid drilling through to the work table,
vice, etc.
If necessary, adjust the required drill depth by means of the drill depth stop in order to achieve a
constant result.
Use a dust remover unit while working with wood. Sawdust can be health hazardous. Also use a
suitable protective mask for any work which generates dust.
4.8 During the working process
The spindle sleeve feed is being performed by the star grip. Make sure that the feed is being at
a regular pace and not too fast.
The reset of the spindle sleeve is being performed by a track recoil spring.
WARNING!
Danger of clothing and / or long hair getting caught.
• Make sure to wear a well-fitting work suit during drilling work.
• Do not use gloves.
• If necessary, wear a hairnet.
ATTENTION!
Danger of collision by the levers of the star grip.
Do not let the star grip get loose when resetting the drill sleeve.
Thin bits break easily.
In case of deep drilling, remove the bit from time to time, to remove drilling chips from the bore
hole. Some drops of oil reduce friction and ensure a longer edge life of the bit.
CAUTION!
Danger of crushing! Do not place your hand between the drill head and the spindle
sleeve.
