Page 16 Drilling machine B 13 / B14 / B16 / B20 / B25 / B32 Version 1.2.5 18 / 01 / 2008
3 Assembly
3.1 Extent of supply
When the drilling machine is delivered, check immediately that the machine has not been dam-
aged during shipping and that all components are included. Also check that no fastening screws
have come loose.
The delivery volume contains:
3.2 Transport
WARNING!
Machine parts falling off forklift trucks or transport vehicles could cause very serious or
even fatal injuries. Follow the instructions and information on the transport case:
• centres of gravity
• suspension points
•weights
• means of transport to be used
• prescribed shipping position
WARNING!
Use of unstable lifting equipment and load-suspension devices that break under load can
cause very serious injuries or even death.
Check that lifting and load suspension gear has sufficient load capacity and that it is in
perfect condition.
B13 / B14 B16 B20
B20 Vario
B25 / B32
B25 Vario
B32 Vario
• drilling head • drilling head • drilling head • drilling head
• drilling table with pre-
mounted clamping lever
• drilling table with pre-
mounted clamping lever
• drilling table
• drilling table support
• handle
• drilling table
• drilling table support
• handle
•stand •stand •stand •stand
• column component with
premounted table sup-
port
• column component with
premounted table sup-
port
• column component
• toothed rod
• guide ring
• column component
• toothed rod
• guide ring
• gear rim drill chuck (B13)
• quick action drill chuck
(B14)
• quick action drill chuck
• morse cone MK2
• drill drift
• quick action drill chuck
• morse cone MK2
• drill drift
• quick action drill chuck
• morse cone MK3
(B25 / Vario)
• morse cone MK4
(B32 / Vario)
• drill drift
• 3 x handle bar star han-
dle
• 3 x handle bar star han-
dle
• 3 x handle rod star han-
dle
• 3 x handle rod star han-
dle
• assembly set • assembly set • assembly set • assembly set
• operating manual • operating manual • operating manual • operating manual
• for 400 V: CEE - 16 A,
phase inverter
• CEE - 16 A,
phase inverter
