TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-51
Single Kickback Parts List
Item
Part Number
Description
1
30W-0180-44
SPACER BLOCK KICKBACK
2
30W-0180-45
PINSPOTTER SUPPORT, TENPIN
3
858-649-087
JCN 1/4-20 BO HDT
4
7024-201400-150
14-10 X 1-1/2 HEX/WASHER HEAD SELF-TAPPING SCREW
5
7024-201400-175
14-10 X 1-3/4 HEX/WASHER HEAD SELF-TAPPING SCREW
6
7028-003100-175
5/16 X 1-3/4 LAG SCREW
7
801-549-807
SJB 1/4-20 X 45MM BO TYBB
8
7050-034068-006
11/32 X 11/16 X 1/16 FLAT WASHER
9
7060-031057-009
5/16 LOCK WASHER
10
M-0180-37-12
KICKBACK U-BAR, 48
11
M-0180-37-8
KICKBACK U-BAR, 24
12
Q88-0180-42
SINGLE KICKBACK
12.1
30W-0180-12
REAR KICKBACK BLOCK
12.2
30W-0180-29
KICKBACK SPACER
12.3
7022-311400-150
#14 X 1-1/2 FLAT HEAD WOOD SCREW
12.4
M88-0181-02
ATTACHMENT PLATE, 2-3/4
12.5
M88-0181-30
WOOD KICKBACK SUPPORT
12.6
W88-0180-30
SINGLE DIVISION KICKBACK
13
051-060-001
U-BAR SHIM
14
051-060-000
U-BAR SHIM
