TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 7/17 Page 3-3
3.0 Troubleshooting
Section Overview
This section contains information that will help you identify and correct
problems that might arise as you use your equipment. The TMS String
Pinspotter’s control chassis contains significant diagnostic tools that can
help you get back up and running quickly in the event of a malfunction.
The control chassis contains a diagnostic text menu that gives status
information for many of the pinspotters subsystems, as well as a graphics
screen that lets you observe many of the machine’s parameters while it is
in operation.
The electronic unit controlling the pinspotting machine and accessed by
the user may be interchangeably called the “chassis,” “controller,” or
“chassis controller.” An electronic unit inside the pinspotter may be
interchangeably called the “pin detector,” “pin detector board,” or “pin
detector box.”
