TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 7/17 Page 1-18
Diagnostics
Pushing the DIAG pushbutton will display the Text Menu, Graphics, and Output Control
submenus.
Text Menu
Selecting text menu will display a list of components that are monitored by the control chassis.
This can be very useful when trying to figure out why the pinspotter isn’t operating normally. A
list of monitored components and their possible states is shown below.
Monitored
Component
Possible States
Additional Information
Backend Breaker
OK, Tripped
Ok when on, Tripped when off.
Backend Motor
On, Off, Asleep
Asleep is a state which the motor turns off after
a period of inactivity during a game.
Ball Detector
Ball, No Ball
Ball Lift
On, Off, Asleep
Asleep is a state which the motor turns off after
a period of inactivity during a game.
Ball Sensor
0, 1
Drive Encoder
0 to 1250 / Valid /
Invalid
This the count for the encoder wheel of the
motor. Invalid indicates either an out of normal
value or the home position has not been set.
Encoder Sensors
A:ON/OFF B:ON/OFF
Monitor both optical sensors of the encoder.
Drive RPM
-900 to 1800
This is the speed the motor controller is asking
the motor to turn.
E-Stop Loop
Closed, Open
Foul detector
Foul, No Foul
Home
Home, Not Home
Lane Breaker
Ok, Tripped
Ok when on, Tripped when off.
Mask Lights On
Go(green), No Go (Red)
Indicates which light of the masking is on.
Mechanic Call
On, Off
Pin Encoder
xx, xx, xx, xx, xx, xx, xx,
xx, xx, xx
Indicates the counts of the pin detectors wheels.
Software
VX.XX
Software version of the chassis.
Stack Lights
Off, Red, Green, Red and
Green
Tenth frame
On, Off
