TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-9
Pit Light Mount Bracket Parts List
Item
Part Number
Description
1
051-080-020
PIT LIGHT HANGER BRACKET
2
051-080-022-01
SHIELD BRACE
3
7050-034100-012
FW 0.34 X 1.00 X 0.13 ZN
4
7060-031057-009
SWM 5/16 ANSI ZN
5
7010-003118-175
HHCS 5/16-18 X 1.75 GR5 ZN
6
801-757-161
FBCS 5/16-18 X 1.00 GR5 BP PA
7
7036-003118-000
HLN 5/16-18 ZN NE
8
7050-021050-006
FW 10 SAE ZN
9
7036-001032-000
HLN 10-32 ZN NM
10
7016-411032-062
PHPMS 10-32 X 0.63 ZN
11
801-757-121
FBCS 5/16-18 X 0.75 GR5 BP PA
12
051-070-025
CARABINER SHIELD TMS
13
948-722-111
FW 5/16 SAE BO
14
051-080-017
07P PIT LIGHT AND SHIELD TRUSS
15
051-080-018
10P PIT LIGHT AND SHIELD TRUSS
16
SB-0700-50-3
SHIELD ASSEMBLY
17
9102163
SHIELD BRACKET
18
SB-043-1
TMS TABLE PULLEY ASSEMBLY
19
9102164
SPACER PULLEY
21
7046-003118-037
EN 5/16-18 NS OBL
22
051-150-002
TMS SHIELD STRING (NOT SHOWN)
