Quectel BG96 Developer's Guide

Integrating with AWS Marketplace using AnyNet
IRIS
AnyNet IRIS enables you to easily and securely deploy required IAM roles and policies to selected
AWSregions for integration with AWS Marketplace.
AnyNet IRIS is supported on the following operating systems:
•
Windows 10 version 1903 and above
•
macOS 10.14 and above
For information about the IAM managed policies you need to use the AnyNet Cellular
Connectivity for AWS IoT SaaS product, see Required IAM Managed Policies.
For information about the IAM permissions you need to use the AnyNet Cellular Connectivity for
AWS IoT SaaS product, see Required IAM permissions.
After deploying resources, you can use AnyNet IRIS to review the status of your things in each region in
a specified time period, view the deployed Cloud Formation template contents, as well as manage
configuration and updates.
For more information, see Reviewing thing connectivity using AnyNet IRIS.
5
Eseye-enabled Quectel BG96 module Developer Guide v1.8
Integrating with AWS Marketplace using AnyNet IRIS

Quectel BG96 Specifications

General

Category	LTE Cat M1/Cat NB1/EGPRS Module
Chipset	Qualcomm MDM9206
LTE FDD Bands	B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
GSM	850/900/1800/1900MHz
Operating Temperature	-40°C to +85°C
Dimensions	23.6mm × 19.9mm × 2.2mm
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
LTE TDD Bands	B39
LTE Cat M1 Data Rate	375 kbps (DL), 375 kbps (UL)
LTE Cat NB1 Data Rate	32 kbps (DL), 70 kbps (UL)
EGPRS Data Rate	296 kbps (DL), 236.8 kbps (UL)
Storage Temperature	-45°C ~ +90°C
Interfaces	UART, USB, PCM, ADC, GPIO
SIM Interface	1.8V/3V
Protocols	TCP/UDP/PPP/FTP/HTTP/MQTT/CoAP
Certifications	CE, FCC, PTCRB
