Quectel BG96 Developer's Guide

About this guide
This guide is designed to help you connect one or more things to Amazon Web Services (AWS) for data
collection, storage and analysis purposes, using the Eseye-enabled Quectel BG96 module. You will also
learn how to control the modem using ATcommands.
This guide uses the plug and play LTE IoT 2 click as a worked example. The LTE IoT 2 click contains the
Quectel BG96 module, and provides a useful proof of concept.
We assume that your thing is designed to transmit data over cellular networks. You must have
knowledge of AT command and cellular modem usage for data communications.
If you want to connect with other cloud providers, or to a private cloud, speak to your Account
Manager.
Extra reading
For general information, see the online help: https://docs.eseye.com/Content/Home.htm
You may prefer to use the Quick Start Guide to connect to the cloud. For more information, see:
8617 LTE IoT 2 click Quick Start Guide (PDF)
For information about the LTE IoT 2 click, see https://www.mikroe.com/lte-iot-2-click.
vi
Eseye-enabled Quectel BG96 module Developer Guide v1.8

Quectel BG96 Specifications

General

Category	LTE Cat M1/Cat NB1/EGPRS Module
Chipset	Qualcomm MDM9206
LTE FDD Bands	B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
GSM	850/900/1800/1900MHz
Operating Temperature	-40°C to +85°C
Dimensions	23.6mm × 19.9mm × 2.2mm
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
LTE TDD Bands	B39
LTE Cat M1 Data Rate	375 kbps (DL), 375 kbps (UL)
LTE Cat NB1 Data Rate	32 kbps (DL), 70 kbps (UL)
EGPRS Data Rate	296 kbps (DL), 236.8 kbps (UL)
Storage Temperature	-45°C ~ +90°C
Interfaces	UART, USB, PCM, ADC, GPIO
SIM Interface	1.8V/3V
Protocols	TCP/UDP/PPP/FTP/HTTP/MQTT/CoAP
Certifications	CE, FCC, PTCRB
