Quectel RM500Q-AE - RF Antenna Port Mapping; Operating Frequency

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 55 / 83
5.1.2. RF Antenna Port Mapping
Table 252524: RM500Q-AE & RM502Q-AE RF Antenna Mapping
5.1.3. Operating Frequency
Table 26: RM500Q-AE&RM502Q-AE Module Operating Frequencies
Antenna
WCDMA
4G
5G NR
LB
(MHz)
MHB
(MHz)
n77
(MHz)
n41
n77/n78/
n79
ANT0
MHB
TRX
MHB_TRx
UHB_PRx MIMO
PRx
MIMO
PRx_
MIMO
–
1452 to
2690
3300 to
4200
ANT1
LB_TRx
LB_TRx
MHB_DRx MIMO,
UHB_DRx MIMO,
LAA PRx
DRx
DRx_
MIMO
617 to
960
1452 to
2690
3300 to
4200
ANT2
LB_DRx
LB_DRx,
MHB_PRx MIMO,
UHB_TRx
1)
TRx
TRx
617 to
960
1452 to
2690
3300 to
4200
ANT3_
GNSSL1
MHB
DRx
MHB_DRx,
UHB_DRX,
LAA_DRx
DRx_
MIMO
DRx
–
1452 to
2690
3300 to
4200
1.
1)
LTE UHB frequency range: 3400–5000 MHz.
1)
LTE UHB frequency range: 3400–5000 MHz.
Band Name
Transmit
(MHz)
Receive
(MHz)
LTE-FDD
LTE-TDD
UMTS
5G NR
PCS (1900)
1850–1910
1930–1990
B2
–
B2
n2
AWS
1710–1755
2110–2155
B4
–
B4
–
Cell (850)
824–849
869–894
B5
–
B5
n5
IMT-E (2600)
2500–2570
2620–2690
B7
–
–
n7
700 lower A–C
699–716
729–746
B12
–
–
n12
700 upper C
777–787
746–756
B13
–
–
–
700 D
788–798
758–768
B14
–
–
–
B17
704–716
734–746
B17
–
–
–
PCS + G
1850–1915
1930–1995
B25
–
–
n25
NOTE
