5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 71 / 83
Table 363635: RF Output Power
1)
For 5G NR TDD bands, the normative reference for this requirement is TS 38.101-1 [2] clause 6.3.1
6.7. RF Receiving Sensitivity
The following tables show conducted RF receiving sensitivity of RM500Q-AE&RM502Q-AE.
Table 37: RM500Q-AE&RM502Q-AE Conducted RF Receiving Sensitivity
Mode
Frequency
Max.
Min.
WCDMA
WCDMA bands
24 dBm +1/-3 dB (Class 3)
< -50 dBm
LTE
LTE bands
23 dBm ±2 dB (Class 3)
< -40 dBm
LTE HPUE bands
(B38/B41/)
26 dBm ±2 dB (Class 2)
< -40 dBm
5G NR
5G NR bands
23 dBm ±2 dB (Class 3)
< -40 dBm
(BW: 5–20 MHz)
1)
5G NR HUPE bands
(n41/n77)
26 dBm +2/-3 dB (Class 2)
< -40 dBm
(BW: 5–20 MHz)
1)
Mode
Frequency
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA
WCDMA B2
TBD
TBD
TBD
-106.7 dBm
WCDMA B4
TBD
TBD
TBD
-106.7 dBm
WCDMA B5
TBD
TBD
TBD
-104.7 dBm
LTE
LTE-FDD B2 (10 MHz)
TBD
TBD
TBD
-96.3 dBm
LTE-FDD B4 (10 MHz)
TBD
TBD
TBD
-96.3 dBm
LTE-FDD B5 (10 MHz)
TBD
TBD
TBD
-94.3 dBm
LTE-FDD B7 (10 MHz)
TBD
TBD
TBD
-94.3 dBm
LTE-FDD B12 (10 MHz)
TBD
TBD
TBD
-93.3 dBm
NOTE
