Quectel RM500Q-AE - Key Features

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 15 / 83
⚫ Other wireless terminal devices
2.2. Key Features
The following table describes key features of RM500Q-AE&RM502Q-AE.
Table 2: Key Features of RM500Q-AE&RM502Q-AE
Feature
Details
Function Interface
PCI Express M.2 Interface
Power Supply
⚫ Supply voltage: 3.135–4.4 V
⚫ Typical supply voltage: 3.7 V
Transmitting Power
⚫ Class 3 (24 dBm +1/-3 dB) for WCDMA bands
⚫ Class 3 (23 dBm ±2 dB) for LTE bands
⚫ Class 3 (23 dBm ±2 dB) for 5G NR bands
⚫ Class 2 (26 dBm ±2 dB) for LTE B38/B40/B41/B42/B43 bands HPUE
1)
⚫ Class 2 (26 dBm +2/-3 dB) for 5G NR n41/n77/n78/n79 bands HPUE
1)
5G NR Features
⚫ Support 3GPP Rel-.15
⚫ Modulations:
Uplink: π/2-BPSK, QPSK, 16QAM, 64QAM and 256QAM
Downlink: QPSK, 16QAM, 64QAM and 256QAM
⚫ Support downlink 4 × 4 MIMO on: n2/n7/25/n41/n66/n77
⚫ Support SCS 15 kHz
2)
and 30 kHz
2)
⚫ Supports 5G NR refarmed band bandwidth ≤ 20 MHz
⚫ Supports 5G NR n41/n77 bandwidth ≤ 100 MHz
⚫ Support SA and NSA operation modes
⚫ Support Option 3x, 3 Aa, and Option 2
⚫ Max. transmission data rates
3)
:
RM500Q-AE
NSA : Max 2.5 Gbps(DL)/ 650 Mbps (UL)
SA : Max 2.1 Gbps(DL)/ 450 Mbps (UL)
RM502Q-AE
NSA : Max 5 Gbps(DL)/ 650 Mbps (UL)
SA : Max 4.2 Gbps(DL)/ 450 Mbps (UL)
LTE Features
⚫ Supports 3GPP Rel-15
⚫ Support up to CA Cat 16 FDD and TDD
⚫ Supported modulations:
Uplink: QPSK, 16QAM and 64QAM and 256QAM
