307
Legend:
S
IZE L X H X P
W
EIGHT
:
V
OLTAGE
:
P
OWER
:
C
OFFEE RESISTOR
:
S
TEAM RESISTOR
:
T
ANK CAPACITY
:
COFFEE BOILER:
S
TEAM BOILER
:
W
ORKING TEMPERATURE
:
280
X
405
X
450
MM
25
K
G
200-240
V
–
50-60
H
Z
/
120
V
–
60
H
Z
2350
W
800W
1400W
3
L
0,75 L
1,40
L
+5°C
÷
+35°C
1. Open the water tank lid. Take out the tank and fill with drinking water,
softened if possible.
2. Connect the machine to an electric socket, switch on the machine with the
general switch (m) and wait for the machine to fill the boiler and reach the
working temperature.
3. Activate the switch of the boiler steam (p) and wait until working pressure is
reached (1,2 Bar).
When used for the first time, with the machine warmed, allow an
outlow of approx.0,5 litres of water to flush the coffee delivery group
and hot water to flush the exchanger circuit.
For this model, the machine temperature management is by
means of the TermoPID (s). For the management of the TermoPID
see the section “
TERMO
P
ID SETTING AND FUNCTIONING
”.
a. Coffee brew group
b. Coffee delivery lever
c. Filter holder
d. Steam valve
e. Steam wand
f. Hot water valve
g. Hot water wand
h. Steam boiler pressure gauge+
Pump pressure gauge
i. Water tank lid
j. Cup warmer
k. Pressure adjustment valve
l. Drip tray
m. General switch ON/OFF
n. Machine green light ON
o. Coffee heating red light
p. Steam switch
q. Steam green light ON
r. Steam heating red light
s. Termopid
t. Water tank
u. Standby/Economy light
