Quicksilver 805PH - Dash Layout

Quicksilver® 805PH — General Informaon
13
15. Dash Layout (Standard Boat)
Helm switch panel
Steering wheel
SC1000 air temperature sensor
Hydraulic steering
Lanyard
Engine key
USB charging port
Helm breaker panel
Engine throle shi control
SC1000 Tachometer
SC1000 Speedometer
Dash Layout (Oponal Equipment)
GPS
Bow thruster control
Stereo
Port engine key
Starboard engine key
Acve trim keypad
Engine throle shi control
Zipwake controller
SC1000 port tachometer
SC1000 starboard tachometer
SC1000 speedometer
Please note that operator vision from the helm may be obstructed by high trim angles of the cra,
along with other factors such as outboard engine trim angles, hull trim plane angles, loading and load
distribuon, speed & acceleraon, transion from displacement to planing mode, sea condions, rain
and spray, darkness and fog, interior lights, posion of tops and curtains, and persons or movable
gear in the operator’s eld of vision.
