Quicksilver 805PH — System & Component Overview and Operaon
37
On/resume buon
O buon
Prole selecon
Acve trim keypad
Acve Trim
17. Zipwake Interceptors (oponal)
Zipwake is a dynamic trim control system that allows the operator to have either an automac or
manual pitch and roll control of the boat. Located on the hull at the transom, there are two
interceptors which level the boat (port to starboard) caused by uneven weight distribuon, too many
people on one side of the vessel, or by strong winds pushing the vessel to one side.
on your GPS. Refer to the GPS owner’s manual for more specic informaon regarding instrucons
and warranty.
16. Acve Trim
Your boat may come equipped with the Acve Trim system from Mercury. Acve Trim automacally
adjusts the engine trim based on boat speed to opmize performance and fuel economy. The system
allows for the owner to either use the default system programmed, or create their own trim prole.
At anyme the user can override the automac trim system by simply pressing the trim buon on the
shier.
The Acve Trim keypad is located on the starboard side of the dash below the shiers. Refer to the
manufacturer’s manual for complete instrucons and warranty.
Zipwake control panel
Interceptors
Zipwake Interceptors
Pitch wheel
Roll wheel
