Quicksilver 805PH — System & Component Overview and Operaon
25
5. Livewell / Raw Water Washdown (oponal)
An oponal livewell and raw water washdown system is available for this boat. If installed, a 21 liter
livewell is located on the starboard side of the sh staon, while the raw water washdown is located
on the port side of the motorwell. The livewell is used to keep baiish alive by circulang seawater
through the tank.
In addion, your boat comes equipped with a secondary manual bilge pump rated at 19L @ 45 strokes
per minute. When not in use, the manual bilge pump is located on the cockpit oor hatch. To use,
place the barrel end into the water you wish to remove, run the aached hose overboard and pump.
Check the funcon of all bilge pumps at regular intervals.
Clear pump inlet from debris.
The bilge pumping system is not designed for damage
control.
Livewell / Raw Water Washdown
Livewell/ raw water pickup valve
Livewell pump
Livewell hose
Aerator
Livewell drain tube / overow
Livewell drain hose
Livewell drain thru hull
Raw water pickup hose
In-line water lter
Raw water pump
Raw water hose
Raw water outlet
Livewell / raw water panel
