Table of Contents
v
Introducon
1. Owner’s Manual ............................................ vi
2. Your Responsibilies ..................................... vi
3. Safety / Warning Labels ................................ vi
4. Dealer Responsibilies ................................. vii
5. Cra Idencaon Number (CIN) ................ vii
6. Warranty Informaon .................................. vii
General Informaon
1. Basic Boat Dimensions & Specicaons ......... 1
2. Vessel Stability................................................ 2
3. Load Capacity ................................................. 2
4. Passenger Locaons ....................................... 3
5. Design Categories ........................................... 3
6. Safety Label Locaons .................................... 4
7. Deck Layout (standard equipment) ............... 6
8. Deck Layout (oponal equipment) ................ 8
9. Cockpit Storage .............................................. 9
10. Salon Layout ................................................... 9
11. Lower Liner Layout ....................................... 10
12. Hardtop ........................................................ 11
13. Curtains ........................................................ 11
14. Thru Hull Locaons ....................................... 12
15. Dash Layout .................................................. 13
16. Navigaon Lights .......................................... 14
17. Engine ........................................................... 15
18. Trailering ...................................................... 15
19. Strong Points ................................................ 16
20. Swim Ladder ................................................. 17
System & Component Overview and Operaon
1. Fuel System .................................................. 18
2. Fresh Water System ..................................... 21
3. Black Water System ...................................... 22
4. Bilge Pumps .................................................. 24
5. Livewell/Raw Water Washdown (oponal) . 25
6. Fish Boxes ..................................................... 26
7. Fire Prevenon ............................................. 28
8. Carbon Monoxide Monitor .......................... 29
9. Bow Anchor Windlass (oponal) .................. 30
10. Stern Anchor Windlass (oponal) ................ 31
11. Bow Thruster (oponal) ............................... 32
12. Steering ........................................................ 34
13. Engine Controls ............................................ 35
14. Emergency Engine Shutdown Switch ........... 36
15. Smartcra® Gauges (oponal) ..................... 36
16. Acve Trim ................................................... 37
17. Zipwake Interceptors (oponal) .................. 37
18. Exterior Helm (oponal) .............................. 38
19. Diesel Heat (oponal) .................................. 40
20. Stereo (oponal) .......................................... 41
21. Windshield Wipers ....................................... 41
22. Fish Staon ................................................... 42
23. Cockpit Flip Seats (oponal) ........................ 42
24. Cockpit Table (oponal) ............................... 43
25. Cockpit Access Door ..................................... 43
26. Bow Lounge Seat .......................................... 43
27. Interior Dinee (2 door version) .................. 44
28. Interior Cabin Table (3 door version) ........... 45
29. Cockpit Sunshade (oponal) ........................ 45
30. Canvas (oponal) ......................................... 46
Electrical Systems
1. DC Electrical ................................................. 47
2. Baeries ....................................................... 47
3. Baery Boxes ............................................... 47
4. Baery Selector Switch ................................ 47
5. Fuses and Breakers ...................................... 48
6. AC Electrical System (oponal) .................... 50
7. Galvanic Isolator (oponal) .......................... 52
8. Baery Charger (oponal) ........................... 52
9. Electrical Schemacs .................................... 53
Maintenance
1. Maintenance ................................................ 57
2. Hull & Deck Surfaces .................................... 57
3. Component Maintenance ............................ 58
Specicaons
1. Translated Specicaon ............................... 61
