Quicksilver 805PH - Emergency Engine Shutdown Switch; Smartcraft Gauges (Optional)

36
Quicksilver 805PH — System & Component Overview and Operaon
Wear the lanyard at all mes when operang the boat. Use
it to stop only in an emergency. DO NOT use it to shut o
the engine during normal operaon
Mechanical & DTS Controls
Engine trim
Engine trim (both engines)
“Throle Only” buon
Track pad
Single Engine DTS Control
Twin Engine Mechanical Control
Emergency Engine Shutdown Switch
Ignion shutdown safety switch
Switch clip (aached to switch)
Lanyard
Switch clip (aached to operator)
14. Emergency Engine Shutdown Switch
Your boat is equipped with an ignion shutdown safety switch. The switch is located at the helm near
the engine keys. The ignion shutdown switch incorporates a shut-o switch and a lanyard. Before
operang the boat, one end of the lanyard must be connected to the shut-o switch while the other
end is connected to the operator. If an emergency arises where the engine must be shut down, pull
the lanyard cord to release it from the shut-o switch, which in turn shuts down the engine(s). This
switch is designed to shut the engine(s) o when the operator of the boat leaves the control staon,
either accidently by falling into the boat, or by being ejected overboard.
The lanyard should be long enough to prevent inadvertent acvaon. Do not let the lanyard become
entangled.
15. SmartCra
TM
System Gauges
The instrument package on your boat includes a SmartCra
TM
tachometer and speedometer mul-
gauge system. By pressing the “mode” buon on the gauge, specic informaon vital to the safe
operaon of the vessel can be displayed. Refer to your SmartCra
TM
gauge owner’s manual for
specic informaon on how to get the most out of the mul-gauge display.
In addion, Quicksilver® oers an oponal factory installed GPS along with Mercury’s Vessel Link
system. If installed, the same engine data that you see on your SmartCra
TM
gauges can be displayed
