Quicksilver 805PH — System & Component Overview and Operaon
lower the anchor. Pushing down on the switch will lower the anchor, while pushing up on the switch
raises the anchor. Similarly, using the handheld remote control key fob, pushing on the down switch
will lower the anchor, while pushing the up on the switch will raise the anchor.
Built in to the stern windlass is an auto stop funcon that shuts the motor down once the anchor is
fully retracted and in the stored posion on the anchor roller. Mounted on the transom, the leaded
core rope goes through a mounng plate containing sensors. A red auto stop located at the end of the
rope will automacally shut the windlass o when it comes in contact with the sensors in the
mounng plate.
11. Bow Thruster (oponal)
The electric bow thruster assists with the maneuvering of your vessel when docking. Access to the
motor is via the forward berth storage area, while the baery and baery switch is located under the
forward salon liner oor access panel.
Operaon from the helm
To operate the thruster, you rst must turn the thruster baery switch to the ON posion. At the
helm, you will noce that lights on the thruster controls are ashing. This indicates that there is power
to the switch. Press the on/o switch on the control panel and the lights will stop ashing and become
solid. This indicates that the thruster is acvated and ready for use.
Stern Anchor Windlass
Stern windlass
Stern eye
Stern anchor roller
Windlass switch
Windlass breaker
Remote key FOB
Before operang the windlass, make sure that the safely
lanyard is removed from the anchor
