In rough seas, the sunshade should be stored to avoid
damage to the rail and or canvas
29. Cockpit Sunshade (oponal)
If installed, an oponal cockpit sunshade is available to provide protecon from the sun. The cockpit
sunshade consists of a rail in the hardtop and a canvas.
Operaon
At the upper corner of the hardtop (port and starboard), there is a plate with a pin that holds the
sunshade rail in place. To extend the sunshade, simply pull the pin on both sides and slide the rail out.
The pins will re-engage and lock the rail when fully extended. To install the sunshade canvas, slide the
welng (piping) located on front edge of the sunshade through the sunshade track installed on the
hardtop. Next connect the sunshade to the sunshade rail using the zippers on the edge of the
sunshade. Finally, connect the sunshade straps to the eyelets on the deck.
Interior Cabin Table
Table
Table leg
Table leg support
Table base
The forward seat base has the ability to allow passengers to sit either facing forward or facing a.
Sliding the seat base a 40cm and placing the backrest to the a hole posions allow a person to sit
facing forward. Sliding the seat base forward and placing the backrest in the forward hole posions
allows a person to sit facing a and allows for installaon of a table.
To install the table, push and lock the table leg into the base plate. Next, place the table onto the table
leg. The table is hinged to all easy access to the seang. When not in use, the table and table leg is
stored under the raised dinee oor.
28. Interior Cabin Table (3 door version)
For the 3 Door version of the 805PH, located on the port side of the salon there is a removable table
that consists of an “L” shaped table base leg along with a circular table.
To install the table, loosen the table leg support located on the a seat base. Slide the “L” shaped
table leg into the support and ghten at a given height. Loosen the table base on the boom side of
the table. Slide the table onto the table leg and ghten. To rotate the table, slightly loosen the base
unl the table rotates, and once in the nal posion, lock the base into place.
