Quicksilver 805PH — System & Component Overview and Operaon
Bow Lounge Seat
Seat backrest
Seat base
Support bracket
Interior Dinee
27. Interior Dinee (2 door version)
On the 2 door version of the 805PH, there is an interior dinee located on the port side of the salon
and consists of a forward movable seat base, a xed a seat base, and a removable dinee table. The
forward and a seat bases allow for seang up to three people. In addion, there is also storage
available under both seat bases (depending on opons) along with storage under the raised dinee
oor. The forward seat base arculates and the removable backrest allows for mulple seang
conguraons.
A seat base
A seat storage
Forward seat backrest
Forward seat base
Forward seat storage
Dinee storage
Forward seat base lock
Forward seat sliding track
Dinee table
Table leg
Table base
Forward Facing Posion A Facing Posion
Dinee Table
