Quicksilver 805PH — Electrical Systems
48
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
Fuses and breakers
ATO/ATC fuse Thermal breaker ANL fuse Magnec breaker
NOTE: Never operate or turn o the baery switch when the engine is running as it may cause
damage to electronic components on the boat. Always operate the switch with the engine and
accessories o.
5. Fuses and Breakers
Your boat will either have fuses or breakers protecng the DC electrical system. If you have to replace
a fuse or electrical breaker, replace only with a fuse or breaker of the same rang. The amperage will
be marked on the fuse or breaker, and it is recommended that you carry spare fuses or breakers.
If a fuse or breaker is replaced with one that has a lower amperage, it may not be sucient to carry
the electrical load of the equipment it is connected to and will cause nuisance failures. If a fuse or
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
Baery and the starboard engine / house baery. The baery switch also has the ability to combine
baery banks for emergency starng. To turn on power to the boat, rotate the switch clockwise 90
degrees to the ON posion. To ulize both baery banks for emergency starng, push the switch in
and rotate clockwise 45 degrees.
The 805PH has a breaker panel at the helm, located below the steering wheel. There are also
addional breakers located on the baery switch panel.
Single Engine Baery Switch Operaon
OFF Posion ON Posion Combine Baeries
