Quicksilver 805PH — System & Component Overview and Operaon
39
Hydraulic Steering
The exterior helm comes with an addional steering helm, steering wheel, and steering hoses that
connects to the base steering system. The operaon of the system is similar, where when you turn the
steering wheel, the helm pump forces hydraulic uid through hoses to and from the steering cylinder
which is connected to the ller arm on the engine. Even though the helms are connected, the steering
wheels will not rotate together when one wheel is turned.
Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
Exterior Helm
Cabin engine control
Exterior helm engine control
Helm transfer switch
Vision from the exterior helm staon is limited. Maintain a
lookout as required. Do not operate at planing speeds from
the exterior helm.
DO NOT TURN THE STEERING WHEEL AT THE HELM THAT
DOES NOT HAVE FULL CONTROL OF THE BOAT.
Dual Helm Single Engine Verado Steering
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Power assist pump
Steering cylinder
