R2Sonic 2024 - Table 14: Sonic 2020;2026 FLS Vertical Beamwidth

Page 80 of 254
Version
6.3
Rev
r012
Date
05-11-2022
Part No. 96000001
Approximate Vertical Beamwidth in Degrees
Setting
100
kHz
170
kHz
200
kHz
250
kHz
300
kHz
350
kHz
400
kHz
450
kHz
Narrow
1
8.7
10
8.7
6.9
5.8
5
4.3
3.7
2
12
13
11
8.7
7.2
6.2
5.4
4.7
3
17
15
12
10
8.3
7.1
6.2
5.4
4
22
17
15
12
9.7
8.3
7.3
6.8
5
25
21
18
14
12
10
8.7
7.7
6
29
26
22
18
15
13
11
9.5
Wide
7
35
35
30
24
20
17
15
14
Default
29
26
22
18
15
13
11
9.5
Table 14: Sonic 2020/2026 FLS Vertical Beamwidth
As an example of the vertical steering: 400 kHz, the steering is ±10°. At 200 kHz, the steering is
± 20°.
