11
200 mm
50 mm
100 mm 100 mm 150 mm
50 mm
The DRV40 must be installed in this orientation only.
These clearance dimensions are recommended for maintenance purposes.
Batteries are not supplied with the DRV40, but must be tted prior to installation.
Do not t rechargeable batteries. (Also see 'Maintenance and Spare Parts'.)
CAUTION! RISK OF FIRE OR PRODUCT DAMAGE IF INCORRECT TYPE OF BATTERY IS FITTED.
DISPOSE OF USED BATTERIES ACCORDING TO THE BATTERY MANUFACTURER'S INSTRUCTIONS.
2 x CR - P2 6V
