44
Motor
Battery
CN3
DB9/RS485
DRV40 Thermistors
Power
Supply
Fuse
Relay
Fuse
Power Supply
(high voltage)
Relay
Remote Thermistors
CN2
Modbus
(See separate guide
www.radacontrols.com/DRV40)
PCB Connections
