© 2020 Radiodetection Ltd 56
Active
Frequencies
Operation
Mode
PTL PTLM
PDL PDLU
PXL
TL PL
DL SL SLQ
H2O+
RD4K
CD Clamp
LPC/LCC
200kHz
DC
Induction
Clamp
CD Clamp
LPC/LCC
(*) DC = Direct Connection, LPC = Live Plug Connector, LCC= Live Plug Connector
14.13 TX 10 iLOC Fault Find locator models
CD pairs
PTL PTLM
PDL PDLU
TL PL H2O+
8KFF
CDFF (See
Current
Direction)
14.14 TX 10 iLOC locator models Current Direction (CD)
frequencies
CD pairs
PTL PTLM
PDL PDLU
H2O+
219.9Hz / 439.8Hz
256Hz / 512Hz
280Hz / 560Hz
285Hz / 570Hz
320Hz / 640Hz
380Hz / 760Hz
460Hz / 920Hz
680Hz / 340Hz (INV)
800Hz / 400Hz (INV)
920Hz / 460Hz (INV)
968Hz / 484Hz (INV)
1168Hz / 584Hz (INV)
1248Hz / 624Hz (INV)
4096 / 8192Hz 'MFCD'
