RADWAG AS series Operating Instruction

6
1. TECHNICAL DATA
AS series balances:
Type
AS
60/C/2
AS
60/220/C/2
AS
110/C/2
AS
160/C/2
AS
220/C/2
AS
310/C/2*
Maximum
capacity
60g 60/220g 110g 160g 220g 310g
Minimal load 1mg 1mg 10 mg 10 mg 10 mg 10 mg
Readability 0,01mg 0,01/0,1mg 0,1 mg 0,1mg 0,1mg 0,1mg
Tare range -60g -220g -110 g -160 g -220 g -310 g
Repeatability 0,02mg 0,02/0,1mg 0,1 mg 0,15 mg 0,15 mg 0,2 mg
Linearity ±0,05mg ±0,05/0,2mg ± 0,3 mg
Pan size Φ 70 mm Φ 85 mm
Sensitivity drift 2 ppm/°C in temperature +15 ° - +35 °C
Working
temperature
+10 ° - +45 °C
Power supply 230V 50Hz AC / 11V AC
Calibration Internal (automatic)
Display LCD with backlight
* balance not verified
Type
AS 140/C/1/CT
AS 140/C/2/CT
AS 240/C/1/CT
AS 240/C/2/CT
AS 320/C/1/CT
AS 320/C/2/CT
Maximum
capacity
140g/700ct 240g/1200ct 320g/1600ct
Minimal load 0,004g/0,02ct 0,004g/0,02ct 0,004g/0,02ct
Readability 0,0002/0,001ct 0,0002g/0,001ct 0,0002g/0,001ct
Tare range -140g/-700ct -240g/-1200ct -320g/-1600ct
Repeatability 0,0002g/0,001ct 0,0004g/0,002ct
Linearity ±0,0002g/0,001ct ±0,0004g/0,002ct
Pan size Φ 85 mm
Sensitivity drift 2 ppm/°C in temperature +15 ° - +35 °C
Working
temperature
+15 ° - +30 °C
Power supply 230V 50Hz AC / 11V AC
Calibration internal (for C/2) or external (for C/1)
Display LCD with backlight

RADWAG AS series Specifications

General

Display	LCD with backlight
Maximum Capacity	Varies by model
Readability	Varies by model
Pan Size	Varies by model
Calibration	Internal or external, depending on model
Stabilization Time	≤ 3 seconds
Interface	RS232, USB
Repeatability (Standard deviation)	Varies by model
Linearity	Varies by model
Net Weight	Varies by model
Protection Class	IP 43
