RAEGuard 2 PID User’s Guide
7
4 Physical Description
The RAEGuard 2 PID can be easily installed and integrated with
various control systems. It is designed with flexible pipe-
holding/wall-mounting options and standard connection terminals.
5 Physical Dimensions
The physical dimensions are as shown:
201mm (7.9")
290 mm
(11.4")
257mm
(5.23")
107mm
(4.2")
