Rae RAEGuard 2 PID - 21 Sensor Parts and Dimensions

RAEGuard 2 PID User’s Guide
66
21 Sensor Parts And Dimensions
DigiPID sensor shown with optional mounting adaptor
8-pin
interface
connector
Sample outlet
Pump connections
Sensor module
PID Lamp
Sensor detector
Teflon O-ring
Sensor cover with
filter installed
Optional
mounting
adapter
Fastening nut
Optional mounting
adapter
Sample inlet
