RAEGuard 2 PID User’s Guide
49
CID1
CID1
same
-40º C < Tamb <
+55º C
-
Um: 28VDC
-
-
Uo: 5.91V
Ui: 6.13V
Uo < Ui;
OK
Io: 0.8A
Ii: 1.5A
Io < Ii;
OK
Po: 1.16W
Pi: 1.225W
Po < Pi;
OK
Co: 30µF
Ci: 20.2µF
Ci < Co;
OK
Lo: 55µH
Li: 1µH
Li < Lo;
OK
As demonstrated in the table above, RAEGuard 2 and DigiPID have
matching entity parameters, which allows the two devices to be
connected to form a single piece of equipment: RAEGuard 2 PID,
with the resulting Ex specification given below, suitable for
installation in hazardous areas defined by zones as Ex d ia IIC T4 Gb.
The marking is found on each of the two connected devices.
Resulting RAEGuard2 PID Ex specification
Ex d ia IIC T4 Gb
-20º C < Tamb < +55º C
