Housing
Teflon O-ring
PID Lamp
Sensor
Module
Attachment
ring
IMPORTANT!
Only handle lamp
by holding sides of
end. Do not touch
flat surface.
Filter
IMPORTANT!
Align hole in filter
with hole in top of
PID sensor to
ensure
unobstructed
sample flow
Inlet/Outlet
