STARTING AND OPERATING 173
PARKSENSE SENSORS
The four ParkSense sensors (six if equipped with
Active Parksense), located in the front fascia/
bumper, monitor the area in front of the vehicle
that is within the sensors’ field of view, and the four
ParkSense sensors, located in the rear fascia/
bumper, monitor the area behind the vehicle that
is within the sensors’ field of view. The front
sensors can detect obstacles from approximately
12
inches (30 cm) up to 47 inches (120 cm) from
the
front fascia/bumper. The rear sensors can
detect obstacles from approximately 12
inches
(30
cm) up to 79 inches (200 cm). These distances
depe
nd on the location, type and orientation of the
obstacle in the horizontal direction.
PARKSENSE WARNING DISPLAY
The ParkSense Warning screen is located within
the instrument cluster display Ú page 104. It
provides visual warnings to indicate the distance
b
etw
een the rear fascia/bumper and/or front
fascia/bumper and the detected obstacle.
PARKSENSE DISPLAY
The warning display will turn on indicating the
system status when the vehicle is in REVERSE or
when the vehicle is in DRIVE and an obstacle has
been detected.
The system will indicate a detected obstacle by
showi
ng a single arc in the left, right, or center
regions based on the obstacle’s distance and
location relative to the vehicle.
If an obstacle is detected in the left, right, or center
regi
ons, the display will show a single arc in the left
and/or right regions and the system will produce a
tone. As the vehicle moves closer to the obstacle,
the display will show the single arc moving closer to
the vehicle and the tone will change from a single
1/2 second tone to slow, to fast, to continuous.
4
