402 SERVICING AND MAINTENANCE
Circuit Breakers
F61 – – Spare
F62 – 10 Amp Red
ITBM / Mod Occupant Class / Mod IAIR Suspension / Mod
HVAC
/ Snsr In car Temp / Rear Coolant Temp / PTS /
Integrated Radar Camera Mod (IRCM) / Humidity Rain & Light
Sensor (HRLS) / Parktronics System Mod (PTS) / RR Axle
Coolant Temp Snsr / Gateway Can-C Trailer TPM Mod
F63 – – Spare
F64 – – Spare
F65 – 10 Amp Red Mod ORC
F66 – 10 Amp Red Run - Accessory Feed
Cavity Cartridge Fuse Micro Fuse Description
Cavity Circuit Breaker Description
CB1 25 Amp Driver Window SW Rear PWR Windows / Overhead SW Rear Defrost
CB2 25 Amp Driver PWR Seat / Driver Seat Memory Mod
CB3 25 Amp Passenger Power Seat / Passenger Seat Memory Mod
CAUTION!
When installing the power distribution center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow
water to get into the power distribution center and possibly result in an electrical system failure.
When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected.
