GETTING TO KNOW YOUR VEHICLE 81
3. Without latching, rotate the tailgate to nearly
closed. Then, while providing support to the
tailgate, slide it slowly to the right, removing
the tailgate from the left pivot.
NOTE:
Rest the tailgate on the bumper so that the entire
tail
gate is secure and supported.
Slide Tailgate To The Right
4. Let the tailgate rest on the support cables
whi
le having the tailgate naturally slide
forward on the bumper.
Tailgate Only Supported By Cables
5. Remove the connector bracket from the sill by
pus
hing inward in the locking tab.
Connector Bracket Location
Locking Tab
6. D
isconnect the wiring harness by pushing on
the
two release tabs, ensuring the connector
bracket does not fall into the sill.
Connected Wiring Harness
WARNING!
For vehicles equipped with a multifunction
tailgate, the tailgate weighs 115 lb (52 kg) and
should be removed by at least two people. Injury
to the customer or damage to the tailgate may
occur if one person tries to remove the
multifunction tailgate.
1 — First Release Tab
2 — Second Release Tab
2
