Operating Manual 1505.3896.12 - 14 177
interlock). For this purpose one line of the input ports is used. The open interlock then
will stop the measurement.
With the R&S EMC32 software started, the function >Extras >Device List is selected.
The dialog for the R&S EMC32 device configuration is displayed.
In the Device list which is shown in the left box, the device type Interlock and device
Interlock OSP is selected.
When pressing this button, the device Interlock OSP is taken over into
the R&S EMC32 device configuration and displayed in the box
Configured Devices
By double-clicking the device Interlock OSP, the dialog for further configuration of the
Device is opened. Please follow the same instructions as described in chapter 8.1.1 in
order to define the interface settings.
Once the device is set to physical mode, the available modules are shown on the tab
Properties.
