Trying Out the Instrument
R&S
®
SMA100B
41Getting Started 1419.8620.02 ─ 07
Connect RF of the R&S SMA100B to a signal analyzer, for example
R&S
®
FSW, to display the generated signal.
For the required settings of the signal analyzer, refer to its user manual or
its online help.
6.2 Generating an RF Frequency Sweep Signal
The "Sweep" operating mode allows you to generate an RF signal with periodi-
cally varying frequencies or amplitudes.
This example deals with an RF signal with varying frequency and constant level.
To configure the sweep, you need to determine a defined start and end frequency
with constant time intervals between the frequency steps.
The sweep function does not require specific options.
1. On the front panel, press the [Preset] key to set a defined initial instrument
state.
2. Set the signal output level, if required, e.g. set "Level > -25 dBm".
3. In the tile diagram, select "Sweep" > "Frequency Sweep".
4. In the "General" tab:
Generating an RF Frequency Sweep Signal
