INSTRUCTION MANUAL
RAV TD8060TWS - RAV TD8060TWSR
RAV TD8080TWS - RAV TD8080TWSR
Code M0230 - rev.1.1
(01/2014)
RAVAGLIOLI S.p.A.
RAVAGLIOLI S.p.A. – 40044 Pontecchio Marconi (BO) Via I Maggio, 3
Page 53/ 64
Tel. (+39) 051/ 67.81.511 – Fax (+39) 051/ 84.64.67
e-mail: rav@ravaglioli.com /http www.ravaglioli.com
Level the Rear heads (mounted on the second
steering axle), leaving the front sensor in their
position, wait until automatically appear the next
page.
Adjust the 2
nd
steering axle, Camber (must be
before unfrozen) and Toe where is possible and
needed. Press F4 to proceed
NOTE: In this page is not allowed to adjust caster
because it has eventually been done previously.
After will appear the summary page and where
is possible to print data or store in the personal
Data Bank.
