10.15 Printout of Measurements taken
By selecting the following key from the customer data entry page
, the following
page will be displayed:
Figure 43
DETECTOR
KEYPAD
PC KEYPAD DESCRIPTION
Repeat steering procedure.
(par. 10.8 on page 32)
It stores the carried out
diagnosis inside a special
“customer database” so as to
allow test later displaying
(par. 10.14 on page 38)
It displays a print preview of
the test carried out
(par. 10.15 on page 39)
It goes back to start page
without storing test
Figure 44
Vehicle and
customer data
entry
