CHAPTER
5
Manual No. 016-0159-831 25
C hapter 5
Console Programming
and Calibration
Important: The SCS 450 console requires the selection of volume rate (US, SI, or TU), speed sensor type
(SP1 or SP2), and valve type (C-SD - standard valve, C-F - fast valve, C-FC - fast close valve,
C-P - PWM valve, or C-PC - PWM close valve). Hold the SELF TEST key to review the
selections.
Console Identification
There may be situations that arise during which it may be necessary to contact Raven Industries with questions
about the SCS 450 system. The SCS 450 console has an identification label affixed that contains information
useful to the Raven customer support team to identify potential issues with the console or system. Please refer
to this information on the console when calling to request assistance.
FIGURE 1. Identification Label
Indicates the firmware
version that was loaded on
the machine at the time it
was manufactured
Indicates the revision level
of the console
Indicates the Raven part
number. This number would
be needed to order a
replacement console.
Indicates the identification
number unique to the
console. Used to identify
when the console was
manufactured and to track
the console if it is sent back
for repair.
