16
6) Selecting C-SD, C-F, C-FC, C-P or C-PC.
a) To select C-Sd, C-F, C-FC, C-P, or C-PC, press until desired code is displayed.
b) Momentarily depress , the DATA display will now display
CAL SELF TEST 00
.
7) Definition of Boom Calibration keys.
Depressing this key displays selected boom number in display.
EXAMPLE: Boom 1 will be displayed as
CAL BOOM 1 CAL
.
Depressing this key after selecting BOOM CAL changes the boom number.
EXAMPLE:
CAL BOOM 1 CAL 0
to
CAL BOOM 2 CAL 0
.
Depressing this key after selecting BOOM CAL changes the boom number.
EXAMPLE:
CAL BOOM 2 CAL 0
to
CAL BOOM 1 CAL 0
.
Enter Boom Data:
a) Select boom 1 CAL.
b) Use boom width as calculated under "CALCULATING BOOM CAL".
c) If a boom is not needed, enter a "0" for the length.
8) Enter SPEED CAL calibration number in .
9) Enter METER CAL calibration number in .
10) Enter appropriate VALVE CAL calibration number (2123, 743, or 43 in .
11) Enter the target RATE 1 (GPA) [lit/ha] {GPK} in .
12) Enter the target RATE 2 (GPA) [lit/ha] {GPK} in .
(If you do not use a second rate, enter the same rate as RATE 1 CAL).
NOTE: When automatic 3 tier system is not in use, RATE 2 should not be more than 20%
different from RATE 1 or spray pattern may suffer.
PROGRAMMING THE CONSOLE IS NOW COMPLETED.
The flashing "CAL" will now extinguish. If not, repeat procedure starting at Step 7. After the console is
programmed, if there is a need to change initial console programming (working units, speed sensor
programs or valve drivers), hold for 30 seconds.
The display will flash the current program setting. Press to switch to the desired selection. Press
to complete entry. Repeat procedure as necessary for speed (SP1, SP2) and valve driver
selections (C-SD, C-F, C-FC, C-P, C-PC).
