CHAPTER
5
Manual No. 016-5034-004 39
C hapter 5
Cab Component
Installation
Install the SmarTrax Node
Mount the SmarTrax Node
FIGURE 1. Node Mounting Location
1. Identify the node mounting location to the right of the operator’s seat.
