Parts Section
38
Rayco RG1645S Copyright © 2012 Rayco Mfg - All Rights Reserved
Printed in U.S.A.
WIRING HARNESS (28147)
FROM WIRE DESCRIPTION GAUGE COLOR TO
PLUG# PIN# (FUNCTION IMPRINT) PLUG# PIN #
01 1 B/B SW 16 TAN/BLK 32 -
01 2 2 SPD 16 ORG/BLK 30 -
01 3 CL SW SIG 16 RED 28 2
01 4 WD NEUT 16 ORG 28 4
01 5 SW PWR 16 GRN SP10 -
01 6 CL RELAY 18 PUR 43 85
01 7 CC VALVE 16 ORG/BLK 38 1
01 8 LGT PWR 18 YLW SP7 -
01 9 START RELAY 18 GRN 42 85
01 10 FUEL SOL RELAY 18 BLU 44 85
01 11 2 SPD SOL 16 ORG SP5 -
01 12 B/B SOL 16 TAN SP8 -
02 A RUN PWR 16 RED SP1 -
02 B FUSED PWR 16 RED SP11 -
03 1 FUSED PWR 16 RED SP11 -
03 2 FUSED PWR 16 RED SP11 -
03 3 WTR TEMP LGT 18 PUR SP9 -
03 5 TACH SIG. 16 GRY 09 1
03 6 CAN + 18 YLW 04 A
03 7 CAN - 18 GRN 04 B
03 8 START SIG 16 BRN 12 7
03 9 SOA SW 18 GRN 48 -
03 11 COMM GRD 16 BLK SP2 -
03 12 COMM GRD 16 BLK SP2 -
05 - AIR FILTER 16 BLU 25 -
06 - COMM GRD 16 BLK SP2 -
07 A BATT PWR 12 RED 46 -
07 B GLOW PLUG SIG 14 BRN SP4 -
08 1 COMM GRD 12 BLK SP2 -
08 2 FUEL SOL 14 ORG SP6 -
08 3 FUEL SOL 14 ORG SP6 -
08 4 BATT LGT 16 GRN 17 -
08 5 WTR TEMP LGT 18 PUR SP9 -
08 6 OIL PRESS LGT 16 BLU 21 -
09 3 START 16 GRN/WHT 42 87
10 - COMM GRD 12 BLK SP2 -
11 A CLUTCH SIG 12 BLU 43 87
11 B COMM GRD 12 BLK SP2 -
12 5 RUN PWR 16 RED SP1 -
12 8 GLOW PLUG SIG 14 BRN 19 -
12 9 GLOW PLUG SIG 14 BRN SP4 -
13 1 IGN SW PWR 12 RED/WHT SP3 -
13 3 GLOW PLUG SIG 14 BRN SP4 -
14 - RUN PWR 16 RED SP1 -
15 - COMM GRD 16 BLK SP2 -
16 1 RUN PWR 16 RED SP1 -
16 3 COMM GRD 16 BLK SP2 -
To Next Page
