Parts Section
39
Copyright © 2012 Rayco Mfg - All Rights Reserved Rayco RG1645S Stump Cutter
Printed in U.S.A.
WIRING HARNESS (28147)
16 4 SOA SW 18 BLK/WHT 47 -
18 - LGT PWR 18 YLW SP7 -
20 - LGT PWR 18 YLW SP7 -
22 - LGT PWR 18 YLW SP7 -
23 - WTR TEMP LGT 18 PUR SP9 -
24 - COMM GRD 16 BLK SP2 -
26 - LGT PWR 18 YLW SP7 -
27 A SW PWR 16 GRN SP10 -
27 B LOCK OUT SW 16 PUR 28 3
28 1 RUN PWR 16 RED SP1 -
29 - SW PWR 16 GRN SP10 -
31 - SW PWR 16 GRN SP10 -
33 A 5A FUSE 16 BLK 34 -
33 B RUN PWR 16 RED SP1 -
35 - COMM GRD 14 BLK SP2 -
36 1 B/B SOL 16 TAN SP8 -
36 2 COMM GRD 16 BLK SP2 -
37 1 B/B SOL 16 TAN SP8 -
37 2 COMM GRD 16 BLK SP2 -
38 2 COMM GRD 16 BLK SP2 -
39 1 2 SPD SOL 16 ORG SP5 -
39 2 COMM GRD 16 BLK SP2 -
40 1 2 SPD SOL 16 ORG SP5 -
40 2 COMM GRD 16 BLK SP2 -
41 1 2 SPD SOL 16 ORG SP5 -
41 2 COMM GRD 16 BLK SP2 -
42 30 IGN SW PWR 12 RED/WHT SP3 -
42 86 COMM GRD 14 BLK SP2 -
43 30 IGN SW PWR 12 RED/WHT SP3 -
43 86 COMM GRD 14 BLK SP2 -
44 30 IGN SW PWR 12 RED/WHT SP3 -
44 86 COMM GRD 14 BLK SP2 -
44 87 FUEL SOL 14 ORG SP6 -
45 - IGN SW PWR 12 RED/WHT SP3 -
49 - COMM GRD 12 BLK SP2 -
50 B COMM GRD 18 BLK SP2 -
50 C WTR TEMP LGT 18 PUR SP9 -
50 D WTR TEMP LGT 18 PUR SP9 -
SPLICE CIRCUITS
SPLICE WIRE DESCRIPTION GAUGE COLOR CONNECTED TO
SP1 RUN PWR 16 RED 02-A, 12-5, 14, 16-1,
28-2, 33-B
SP2 COMM GRD 16, 14, 12 BLK 03-11, 03-12, 06,
08-1, 10, 11-B, 15,
16-3, 24, 35, 36-2,
37-2, 38-2, 39-2,
40-2, 41-2, 42-86,
43-86, 44-86, 49,
50-B
SP3 IGN SW PWR 12 RED/WHT 13-1, 42-30, 43-30,
44-30, 45
SP4 GLOW PLUG SIG 14 BRN 07-B, 12-9, 13-3
SP5 2 SPD SOL 16 ORG 01-11, 39-1, 40-1,
41-1
SP6 FUEL SOL 14 ORG 08-2, 08-3, 44-87
SP7 LGT PWR 18 YLW 01-8, 18, 20, 22, 26
SP8 B/B SOL 16 TAN 01-12, 36-1, 37-1
SP9 WTR TEMP LGT 18 PUR 03-3, 08-5, 23, 50-
C, 50-D
SP10 SW PWR 16 GRN 01-5, 27-A, 29, 31
SP11 FUSED PWR 16 RED 02-B, 03-1, 03-2
SPLICE CIRCUITS (28147)
