Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
Send: “EEC\r”
Return: “EEC\r”
Disable Hardware Emission Control
Send: “DLE\r”
Return: “DLE\r”
Enable Hardware Emission Control
Send: “ELE\r”
Return: “ELE\r”
Send: “EMOFF\r”
Return: “EMOFF\r”
Send: “EMON\r”
Return: “EMON\r”
Send: “MPWRON\r”
Return: “MPWRON\r”
Send: “SPW 100\r”
Return: “SPW:100\r”
（Set pulse width as 100ms）
Other return values:
“ERR: input Err\r”
（Input pulse width ＜0.0001）
“ERR: Out of Range\r”
（Over maximum pulse width）
“ERR: Duty Cycle too High\r”
“ERR: Duty Cycle too Low\r”
“SPW:100, Duty=100%\r”
Set Pulse Repetition Rate
Send: “SPRR 1000\r”
Return: “SPRR：1000\r”
“ERR: input Err\r”
“ERR: Out of Range\r”
“ERR: Duty Cycle too High\r”
“ERR: Duty Cycle too Low\r”
“SPW: 100, Duty=100%\r”
Set Diode Current （%）
The set value must be less than 100% and above the
minimum current setting value, which can be set to
0. If the set value is greater than 100, the default is
input 100.
Send: “SDC 100\r”
Return: “SDC：100\r”
Other return values:
“ERR: Input Err\r”
“Laser is worked in AD Mode\r”
Send: “RCS\r”
Return: “RCS: 56.7\r”
(The current set value is 56.7 %)
Read Pulse Repetition Rate (Hz)
Send: “RPRR\r”
Return: “RPRR:10\r”
(Repeat frequency is10Hz)
