Raymarine AXIOM+ Series User Manual

ProductnumberNameDescription
E70634
Axiom™7+
7”MFDChartplotter
.
E70634–DISP
Axiom™7+
7”MFDChartplotter(suppliedwith
R
earmountkitonly).
E70635Axiom™7+R
V3D7”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70635–03
Axiom™7+R
V3D(includingRV–100
transomtransducer)
7”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70635–DISPAxiom™7+R V3D7”MFDwithbuilt-inRealVision™3D
sonarmodule(suppliedwithRear
mountkitonly).
E70636Axiom™9+9”MFDChartplotter .
E70636–DISPAxiom™9+
9”MFDChartplotter(suppliedwith
R
earmountkitonly).
E70637Axiom™9+R V3D9”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70637–03
Axiom™9+R V3D(includingRV–100
transomtransducer)
9”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70637–DISPAxiom™9+R V3D9”MFDwithbuilt-inRealVision™3D
sonarmodule(suppliedwithRear
mountkitonly).
E70638Axiom™12+12”MFDChartplotter .
E70638–DISPAxiom™12+
12”MFDChartplotter(suppliedwith
R
earmountkitonly).
E70639Axiom™12+R V3D12”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70639–03
Axiom™12+R V3D(includingRV–100
transomtransducer)
12”MFDwithbuilt-inRealVision™3D
sonarmodule.
E70639–DISPAxiom™12+R V3D12”MFDwithbuilt-inRealVision™3D
sonarmodule(suppliedwithRear
mountkitonly).
Documentandproductinformation
15

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
