2.
1Productdocumentation
Thefollowingdocumentationisapplicabletoyourproduct:
AlldocumentsareavailabletodownloadasPDFsfromwww.raymarine.com
Documentation
DescriptionP
artnumber
Installationinstructions(Thisdocument)
87414
Surface/Flushmountingtemplate
•7”—87295
•9”—87296
•12”—87297
FrontinstallationkitInstallationinstructions
87304
L egacyMFDtoAxiomadaptorplatesinstallation
instructions
87316
RCR-SDUSBInstallationinstructions87317
LightHouse™3Basicoperationinstructions
81369
LightHouse™3Advancedoperationinstructions
81370
LightHouse™3MFDOperationinstructions
ForoperationinstructionsforyourproductpleaserefertotheLightHouse™3MFDOperation
instructions.
TheBasic(81369)andAdvanced(81370)LightHouse™3OperationInstructions
canbedownloadedfromtheRaymarinewebsite:www.raymarine.com/manuals.
Pleasecheckthewebsitetoensureyouhavethelatestdocumentation.
2.2Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
Axiom™+MultifunctionDisplays
